SKY RC D750 MIX Charger 1600W

• SkyRC D750 MIX Charger – LiPo 1-8S, 32A, 500W AC / 1600W DC

  De SkyRC D750 MIX is a powerhouse and versatile all-in-one charger, specially designed for professionals and demanding users. Thanks to the combination of dual AC/DC input and output, two independent displays and numerous innovative features, this charger is suitable for the toughest applications.

  With a maximum load capacity of no less than 500W via AC and until 1600W via DC, and a charging current up to 32A per channel, the D750 MIX delivers top performance with virtually all popular battery types, including LiPo, LiFe, Li-ion, Pb, NiMH and NiCd. The charger supports batteries of 1 to 8 cells (S) and also offers extensive safety mechanisms for safe and efficient charging.

  Most important features:

  • High power: up to 500W AC even 1600W DC output

  • Supports LiPo, LiFe, Li-ion, LiHV, Pb, NiMH and NiCd batteries

  • Charges batteries from 1 to 8 cells (S) for LiPo and up to 20 cells for NiMH/NiCd

  • Maximum charging current up to 32A per channel, parallel charging possible up to 50A

  • Dual AC/DC input and output with two independent displays

  • USB PD 3.0 support @ 20W for extra flexibility

  • Various protections such as overvoltage protection, overheating protection and more

  Technical Specifications:

  Characteristic	Specification
  Input voltage DC	9-49V
  Input voltage AC	100–240V (50/60Hz)
  Charging capacity AC	500W (per channel)
  Charging capacity DC	1100W per channel, total 1600W
  Charging current LiPo/LiFe/Li-ion/LiHV (2–8S)	0.1A - 32.0A
  Charging current LiPo (1S) / NiMH / NiCd	0.1A - 10.0A
  Charging current Pb	0.1 - 15.0A
  Parallel charging current	33.0A - 50.0A
  Discharge current	0.1A - 4.0A
  External discharge current	0.5A - 40A
  Balancer current	max. 1.9A
  DC power supply output	5V–36V, 0.3A–32A
  Supported battery types	LiPo/LiFe/Li-ion/LiHV: 1–8S NiMH/NiCd: 1–20S Pb: 3S / 6S / 12S
  Weight	1626 gram
  Dimensions	180 × 136 × 112 mm
